IP Camera Module, 2MP

Product Brief

---

- 1/2.8" SONY IMX307 CMOS sensor

- Ambaralla S3L33M SoC

- 2 Megapixels

- Starlight series with supreme low light performance

- Video codec: H.265, H.264, MJPEG

- Triple individually configurable video streams

- Up to 30 fps in 1920 x 1080 resolution; 30fps in all other resolutions

- Power over Ethernet (optional)

- Supporting ONVIF Profile S

Download Datasheet

Specification


Image Sensor:Sony IMX307LQR-C, 1/2.8” , 2.16Megapixel RGB Bayer Array CMOS Sensor

Number of Effective Pixels :1945(H) x 1097(V) approx. 2.13M pixels

Scanning Mode:Progressive Scan

CAMERA

Wide Dynamic Range:DOL HDR (Digital Over Lab High Dynamic Range)

Day and Night Mode: Automatic, Day, Night

Noise Reduction: 3D-NR

Auto Exposure Mode: Automatic, Manual

Shutter Speed Control: Automatic: Min. 1/30,000 sec ~ Max. 1/30 sec, Manual: Min. 1/30,000 sec ~ Max. 1/30 sec

Gain Control Automatic: Min. 0dB ~ Max. 69dB Manual: Min. 0dB ~ Max. 69dB

Auto White Balance Mode: Automatic, Outdoor, Shade, Clear sky, Fluorescent light, Light bulb, Manual

Auto Focus (Optional): One Push, Manual, (Automatic)

Optical Zoom (Optional): Motorized 4.2x

Optical Zoom Speed (Optional): 1~6 Steps

Digital Zoom: 8x

On Screen Display: On/Off

Back Light Compensation: On/Off

High Light Compensation: On/Off

Image Effect: Mirror, Flip

Privacy Mask: Max.8 Area Selection

Tamper: On/Off

Video Motion Detection: Max.4 Area Selection

Corridor Format: 90°/270°

Lens Distortion Compensation: On/Off

NETWORK

Video Compression: H.265 Main profile,H.264(High, Main), MJPEG

Video Resolution: 1920x1080, 1280x720,1024x576, 768x432, 704x392, 640x360, 384x216

Video Frame Rate: Up to 30fps@1920x1080p

Video Streaming: Simultaneously H.265 and H.264 and MJPEG (Quad Streaming), Independent Frame Rate and Bandwidth Control, VBR/CBR Mode

Audio Streaming: Two way(G.711)

FTP Uploading: MJPEG Still Image

Event In: Onboot/Trigger/Network Loss/Tampering/Motion

Event Out: Notification E-mail, FTP

Login Authority: Administrator, Operator, Guest

Event Buffering: FTP : Pre/Post Event Time: 0~30sec, FPS: 1~2 fps

Manual Trigger: Still Image Capture

Security: Multi User Authority, IP Filtering, HTTPS

Network Time Sync: Synchronize Computer/NTP Server, Manual

Software Reset: Restart, Reset, Factory Default

Auto Recovery: Backup, Restore

Remote Upgrade: Using Web Browser

Protocols: TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour, SNMP

Client Software: Built-In Web, ONVIF Compatible 3rd Party VMS

Max. User Connection: 10 Users

SDK Support: API, ONVIF Profile S/T Compliant

EXTERNAL IN/OUT

Ethernet Tx/Rx: RJ-45(10/100Base-T)

IR_LED Control: IR_LED Control On/Off

Day & Night Control: IR_Cut_Filter Exchange

Iris Control: DC-Iris, Fixed

Alarm Control: Alarm-In 1/Alarm-Out 1

SD Card: SDHC/SDXC

Audio: Line-In/Line-Out

USB: USB 2.0

CVBS(or UART): Composite Out(or Serial TX/RX)

Zoom Control: Max. 4.2x

Focus Control: One-Push, Manual, (Automatic)

OPERATION ENVIRONMENTS

Operating Humidity: 0~90% (non-condensing)

Operating Temperature: 0℃~ +50℃

Power Supply: DC12V

Power Consumption: 4W(without IR_LED)

Dimension: 42.0(W) x 42.0(D) x 7.3(H)mm

Weight: 15g
